Carrier SEER 48ES - Manual (Page 25)

25
Table 9 -- Dry Coil Air Delivery* -- Horizontal and Downflow Discharge --
Unit 48ES024--060
Unit
Heating
Rise Range
Motor
Speed
Wire
Color
External Static Pressure (in. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
48ES(---,N)048090
35 --- 65 o F
(19 --- 36 o C)
Low 1 Blue
CFM 1402 1351 1311 1263 1224 1172 1136 1080 1041
Heating
Rise ( o F)
49 50 52 54 56 58 60 63 65
Heating
Rise ( o C)
27 28 29 30 31 32 33 35 36
Med---Low Pink
CFM 1457 1404 1367 1318 1284 1233 1197 1144 1104
Heating
Rise ( o F)
47 48 50 52 53 55 57 59 62
Heating
Rise ( o C)
26 27 28 29 29 31 32 33 34
Medium 2 Red
CFM 1736 1695 1642 1601 1553 1512 1465 1427 1381
Heating
Rise ( o F)
39 40 41 42 44 45 46 48 49
Heating
Rise ( o C)
22 22 23 24 24 25 26 26 27
Med---High Orange
CFM 2149 2111 2062 2026 1980 1945 1905 1864 1793
Heating
Rise ( o F)
NA NA NA NA NA 35 36 36 38
Heating
Rise ( o C)
NA NA NA NA NA 19 20 20 21
High Black
CFM 2344 2306 2259 2203 2141 2070 1991 1902 1803
Heating
Rise ( o F)
NA NA NA NA NA NA NA 36 38
Heating
Rise ( o C)
NA NA NA NA NA NA NA 20 21
48ES(---,N)048115
30 --- 60 o F
(17 --- 33 o C)
Low Blue
CFM 1402 1351 1311 1263 1224 1172 1136 1080 1041
Heating
Rise ( o F)
NA NA NA NA NA NA NA NA NA
Heating
Rise ( o C)
NA NA NA NA NA NA NA NA NA
Med---Low Pink
CFM 1457 1404 1367 1318 1284 1233 1197 1144 1104
Heating
Rise ( o F)
60 NA NA NA NA NA NA NA NA
Heating
Rise ( o C)
33 NA NA NA NA NA NA NA NA
Medium 2 Red
CFM 1736 1695 1642 1601 1553 1512 1465 1427 1381
Heating
Rise ( o F)
50 51 53 54 56 57 59 NA NA
Heating
Rise ( o C)
28 28 29 30 31 32 33 NA NA
Med---High 1 Orange
CFM 2149 2111 2062 2026 1980 1945 1905 1864 1793
Heating
Rise ( o F)
40 41 42 43 44 45 46 47 48
Heating
Rise ( o C)
22 23 23 24 24 25 25 26 27
High Black
CFM 2344 2306 2259 2203 2141 2070 1991 1902 1803
Heating
Rise ( o F)
37 38 38 39 41 42 44 46 48
Heating
Rise ( o C)
21 21 21 22 23 23 24 25 27
48ES(---,N)048130
35 --- 65 o F
(19 --- 36 o C)
Low Blue
CFM 1402 1351 1311 1263 1224 1172 1136 1080 1041
Heating
Rise ( o F)
NA NA NA NA NA NA NA NA NA
Heating
Rise ( o C)
NA NA NA NA NA NA NA NA NA
Med---Low Pink
CFM 1457 1404 1367 1318 1284 1233 1197 1144 1104
Heating
Rise ( o F)
NA NA NA NA NA NA NA NA NA
Heating
Rise ( o C)
NA NA NA NA NA NA NA NA NA
Medium 2 Red
CFM 1736 1695 1642 1601 1553 1512 1465 1427 1381
Heating
Rise ( o F)
55 57 59 60 62 64 NA NA NA
Heating
Rise ( o C)
31 32 33 33 34 35 NA NA NA
Med---High 1 Orange
CFM 2149 2111 2062 2026 1980 1945 1905 1864 1793
Heating
Rise ( o F)
45 46 47 48 49 50 51 52 54
Heating
Rise ( o C)
25 25 26 26 27 28 28 29 30
High Black
CFM 2344 2306 2259 2203 2141 2070 1991 1902 1803
Heating
Rise ( o F)
41 42 43 44 45 47 48 51 53
Heating
Rise ( o C)
23 23 24 24 25 26 27 28 30
