128
Using the AC Adapter Kit (Sold Separately)
You are advised to use AC Adapter Kit ACK-DC20* (sold separately)
for long periods of use and when connecting to a computer or printer.
* Consists of Compact Power Adapter CA-PS700, DC Coupler DR-20 and DR-
700 (Not available on the PowerShot S80) and a power cord.
1
Attach the power cord to the compact power adapter ( a )
and plug it into a power outlet ( b ).
Plug in the power cord firmly as far as it will go.
2
Connect the DC plug of the compact power adapter cable
to the DC Coupler DR-20 terminal.
3
Open the memory card slot/battery cover, then insert the
DC Coupler until it is locked.
Connect to
Power Supply
Compact Power Adapter
CA-PS700
DC Coupler
DR-20
Battery lock
