CY7C1380D, CY7C1382D
CY7C1380F, CY7C1382F
Document #: 38-05543 Rev. *F
Page 26 of 34
Figure 13. ZZ Mode Timing
Switching Waveforms
(continued)
t
ZZ
I
SUPPLY
CLK
ZZ
t
ZZREC
ALL INPUTS
(except ZZ)
DON’T CARE
I
DDZZ
t
ZZI
t
RZZI
Outputs (Q)
High-Z
DESELECT or READ Only
Notes
30. Device must be deselected when entering ZZ mode. See
on page 10 for all possible signal conditions to deselect the device.
31. DQs are in high-Z when exiting ZZ sleep mode.
