Dell PowerEdge SC1435 - Manual (Page 11)

Four-Post Rack Installation
9
Static Rails Rack Kit Contents
• One pair of static mounting rails with either VersaRails brackets or RapidRails brackets.
• One pair of chassis static rail modules
• 10-32 x 0.5-inch flange-head Phillips screws (8) (VersaRails kits only)
• Releasable tie wraps (2) (not shown in Figure 1-2)
NOTE:
The nonmetric screws described in illustrations and in procedural steps are identified by size and number
of threads per inch. For example, a #10 Phillips-head screw with 32 threads per inch is identified as a 10-32 screw.
Figure 1-2. Static Rails Rack Kit Contents
1 10-32 x 0.5-inch flange-head
Phillips screws (8)
(VersaRails kits only) 2 static mounting rails (2) 3 chassis static rail modules (2)
FRONT
L
1
3
2
