CY7C1019CV33

Document #: 38-05130 Rev. *F

Page 3 of 10

Maximum Ratings

(Above which the useful life may be impaired. For user guide-
lines, not tested.)

Storage Temperature ................................. –65°C to +150°C

Ambient Temperature with
Power Applied............................................. –55°C to +125°C

Supply Voltage on V

CC

to Relative GND

[2]

.... –0.5V to +4.6V

DC Voltage Applied to Outputs
in High-Z State

[2]

....................................–0.5V to V

CC

+ 0.5V

DC Input Voltage

[2]

.................................–0.5V to V

CC

+ 0.5V

Current into Outputs (LOW)......................................... 20 mA

Static Discharge Voltage............................................ >2001V
(per MIL-STD-883, Method 3015)

Latch-up Current...................................................... >200 mA

Operating Range

Range

Ambient

Temperature

V

CC

Commercial

0°C to +70°C

3.3V

± 10%

Industrial

–40

°C to +85°C

3.3V

± 10%

Electrical Characteristics

Over the Operating Range

Parameter

Description

Test Conditions

–10

–12

–15

Unit

Min.

Max.

Min.

Max.

Min.

Max.

V

OH

Output HIGH Voltage V

CC

= Min.,

I

OH

= –4.0 mA

2.4

2.4

2.4

V

V

OL

Output LOW Voltage

V

CC

= Min.,

I

OL

= 8.0 mA

0.4

0.4

0.4

V

V

IH

Input HIGH Voltage

2.0

V

CC

+ 0.3

2.0

V

CC

+ 0.3

2.0

V

CC

+ 0.3

V

V

IL

Input LOW Voltage

[2]

–0.3

0.8

–0.3

0.8

–0.3

0.8

V

I

IX

Input Leakage Current GND < V

I

< V

CC

–1

+1

–1

+1

–1

+1

µA

I

OZ

Output Leakage
Current

GND < V

I

< V

CC

,

Output Disabled

–1

+1

–1

+1

–1

+1

µA

I

CC

V

CC

Operating

Supply Current

V

CC

= Max.,

I

OUT

= 0 mA,

f = f

MAX

= 1/t

RC

80

75

70

mA

I

SB1

Automatic CE
Power-down Current
—TTL Inputs

Max. V

CC

, CE > V

IH

V

IN

> V

IH

or

V

IN

< V

IL

, f = f

MAX

15

15

15

mA

I

SB2

Automatic CE
Power-down Current
—CMOS Inputs

Max. V

CC

,

CE > V

CC

– 0.3V,

V

IN

> V

CC

– 0.3V,

or V

IN

< 0.3V, f = 0

5

5

5

mA

Capacitance

[3]

Parameter

Description

Test Conditions

Max.

Unit

C

IN

Input Capacitance

T

A

= 25°C, f = 1 MHz,

V

CC

= 5.0V

8

pF

C

OUT

Output Capacitance

8

pF

Notes:

2. V

IL

(min.) = –2.0V for pulse durations of less than 20 ns.

3. Tested initially and after any design or process changes that may affect these parameters.
