CY7C1019CV33
Document #: 38-05130 Rev. *F Page 2 of 10
Pin Configuration [1]
Selection Guide
-10 -12 -15 Unit
Maximum Access Time 10 12 15 ns
Maximum Operating Current 80 75 70 mA
Maximum Standby Current 5 5 5 mA
Note:
1. NC pins are not connected on the die.
WE
V
CC
A
9
A
16
NC
A
4
A
2
A
1
CE
NC
I/O
0
I/O
1
A
5
A
0
NC
NC
NC
I/O
2
I/O
3
V
SS
A
10
A
3
OE
V
SS
NC
I/O
7
NC
NC
A
13
A
7
A
6 NC
V
CC
I/O
6
NC
NC
NC
I/O
4
I/O
5
A
8
A
11
A
14
A
12
A
15
NC
NC NC
3 2 6 5 4 1
D
E
B
A
C
F
G
H
NC
48-ball VFBGA
(Top View)
