T--298 1-3
Table 1-2 Additional Support Manuals
MANUAL--FORM NO. EQUIPMENT COVERED TYPE OF MANUAL (For) PART NO.
71LC6A54310 AirV 115 Volts--Free Blow (Cool Only) Owner’s Guide
99--00469--00
99--00469--01
71LH6A54070 AirV 115 Volts--Free Blow (Heat--Cool) Owner’s Guide
99--00469--02
99--00469--03
71LD6A54070 AirV 115 Volts--Ducted (Cool Only) Owner’s Guide 99--00469--06
71LH6A54070 AirV 220 Volts--Free Blow (Heat--Cool) Owner’s Guide
99--00469--08
99--00469--09
71RQ6A5401A AirV 115 Volts--Free Blow (Heat Pump) Owner’s Guide
99--00469--11
99--00469--12
71DQ6A5401A AirV 115 Volts--Ducted (Heat Pump) Owner’s Guide 99--00469--13
71DW6A54070 AirV 115 Volts--Ducted Wired Thermostat Owner’s Guide 99--00469--22
71LC6A54310 AirV 115 Volts--Free Blow (Cool Only) Owner’s Guide
99--00469--23
99--00469--24
71LH6A54070 AirV 115 Volts--Free Blow (Heat--Cool) Owner’s Guide
99--00469--25
99--00469--26
71RW6A54310 AirV 115 Volts--Free Blow Wired Thermostat Owner’s Guide 99--00469--29
T--298PL AirV Service Parts ALL
62--50455--00 Basic refrigeration Service Training ALL
1
2
4
5
3
1. Cover
2. Condenser
3. Evaporator
4. Compressor
5. Base Pan
Figure 1-2 Roof Unit Component Identification
