Manufacturer-specific objects (GK437 objects)
3000h Identifier/command
pointer on SUB-bus
U32
rw
Pointing on a SUB-bus user,
Pointing on a SUB-bus identifier
Pointing on a SPA command
3100h SUB-Bus
Transparent transfer
Octet
String
14 Byte
rw
Read/write SPA command
Array of [14] Bytes
3203h Auto Scan SPA
U08
rw
1h=on
1 = Automatic scan of SPA On
0 = Automatic scan of SPA Off
3204h Check
Position
REC
00h Maximum Subindex U8
ro
01h Total of SPAs ‚not in
position’
U8
ro
Total of all RS485 SUB-bus user recognised
being ‚not in position'
02h SPA SUB-bus
identifier 0..31
U8
ro
SPA with SUB-bus identifier 0..31 ‚not in
position’
03h SPA SUB-bus
identifier 32..63
U32
ro
SPA with SUB-bus identifier 32..63 ‚not in
position’
04h SPA SUB-bus
identifier 64..95
U32
ro
SPA with SUB-bus identifier 64..95 ‚not in
position’
05h SPA SUB-bus
identifier 96..99
U32
ro
SPA with SUB-bus identifier 96..99 ‚not in
position’
3205h SPAs connected
REC
00h Maximum Subindex U8
ro
01h Total of all SPAs
connected
U8
ro
Total of all RS485 SUB-bus users recognised
02h SPA SUB-bus
identifier 0..31
U32
ro
SPA with SUB-bus identifier 0..31
03h SPA SUB-bus
identifier 32..63
U32
ro
SPA with SUB-bus identifier 32..63
04h SPA SUB-bus
identifier 64..95
U32
ro
SPA with SUB-bus identifier 64..95
05h SPA SUB-bus
identifier 96..99
U32
ro
SPA with SUB-bus identifier 96..99
3206h SPA with error signal REC
00h Maximum Subindex U8
ro
01h Total of all SPAs
connected in ‚e’ error
status
U8
ro
Total of all RS485 SUB-bus users recognised
being in error status ‚e’
02h SPA SUB-bus
identifier 0..31
U32
ro
SPA with SUB-bus identifier 0..31 being in
error status ‚e’
03h SPA SUB-bus
identifier 32..63
U32
ro
SPA with SUB-bus identifier 32..63 being in
error status ‚e’
04h SPA SUB-bus
identifier 64..95
U32
ro
SPA with SUB-bus identifier 64..95 being in
error status ‚e’
05h SPA SUB-bus
identifier 96..99
U32
ro
SPA with SUB-bus identifier 96..99 being in
error status ‚e’
