5. Error messages during data transfer
If receiving an invalid data protocol from the PC (for example line not existing or letters where there should
be numbers) the counter
– provided it is still accessible - will return a corresponding error message. To be
able to do so, at least control character and identifier must be correct. If not, NE216 is no longer ac-
cessible and therefore not in a position to reply any error message to the PC.
In case no reply neither error message is replied on the PC request, it is a fatal error which means control
character and identifier are missing. Furthermore, PC and NE216 interface parameters are not con-
gruent. However these being correct, the failure is due to hardware or a defect in the data transmission line.
Standard structure in error messages:
Identifier line status error number
Example: Identifier =35, Line =09 (invalid line), error number =2
3509R2
The error message replied will come without „line“ and „status“ information.
Detailed error description:
Error 1: Format error (incorrect position. This signal is given in case
the data format was not kept during programming (for example during
parameterization of a limit only 4 digits instead of 5 have been
transferred).)
Error 2: Line (position) not existing or separating line
Error 3: Parameter error (invalid protocol data). Example: Scaling factor not
only comprising numbers but also of other characters not permitted, or
parameter beyond the permitted range.
6. Chart of the control characters applied
Control character Hex Decimal
02 02
03 03
06 06
0A 10
0D 13
11 17
18 24
7F 127
