Encoder operating parameters 4.
Significance of operating parameters
Product Device
Name
Resolution per turn
0x6001
Number of turns
0x6502
Measuring range
0x6002
Dezimal Hex Bit Dezimal Hex Bit Dezimal Hex Bit
BMSx GCAMW_H 4096 1000 12 1 1 0 4096 1000 12
BMMx GCMMW_H 4096 1000 12 65536 10000 16 268435456 10000000 28
GXAMW(S) GXAMW_H 8192 2000 13 1 1 0 8192 2000 13
GXMMW(S) GXMMW_H 8192 2000 13 65536 10000 16 536870912 20000000 29
GBAMW(S) GBAMW_H 262144 40000 18 1 1 0 262144 40000 18
GBMMW(S) GBMMW_H 262144 40000 18 16384 4000 14 4294967296 100000000 32
The enabled scaling functionality in CoE is prerequisite for further user-specific parameterization
such as resolution, total measuring range, direction of rotation and preset.
See chapter: SDO (Service Data Objects)
