Introduction 1.
1.1 Scope of delivery
Please check the delivery upon completeness prior to commissioning.
Depending on encoder configuration and part number delivery is including:
Basic encoder, bus cover and CD with describing file and manual (also available as download)
1.2 Product classification
Product mechanics
Solid / Hollow shaft / Kit Product name
(according to object 1008) Description
BMMV / BMMH / BMMK GCMMW_H MT, MAGRES
BMSV / BMSH / BMSK GCAMW_H ST, MAGRES
GBMMW / GBMMS / - GBMMW_H MT, Optical, 18 Bit ST
GBAMW / GBAMS / - GBAMW_H ST, Optical, 18 Bit ST
GXMMW / GXMMS / - GXMMW_H MT, Optical, 13 Bit ST
GXAMW / GXAMS / - GXAMW_H ST, Optical, 13 Bit ST
Note:
Ever apply the matching device file (BAUMER Group absolute EtherCAT encoders.xml) on the above device
types.
Explanation:
MT
Multiturn encoder
ST Singleturn encoder
MAGRES Extremely robust encoder with magnetic sensing principle
18 Bit ST High resolution encoder – up to 18 bit physical singleturn resolution, i.e. 2 18 steps / revolution
13 Bit ST Max. 13 bit physical singleturn resolution, i.e. 2 13 steps / revolution
