Baumer BA Scatec2 - Manual

SCATEC-2
Laser Copy Counter
FLDK 110G1003/S14
FLDK 110G1003/S42
FLDK 110C1003/S42
FLDK 110G1005/S14
FLDK 110G1005/S42
FLDK 110G1006/S14
FLDK 110x10/xxxxxx
User manual
Manual SCATEC-2 2 Baumer Electric AG
Version 2011-05 www.baumer.com Frauenfeld, Switzerland
General notes
Rules for proper
usage This product represents a precision measuring device which has been
designed for the detection of objects and parts. It generates and provides
measured values issued as electrical signals for following systems.
Unless this product has not been specifically marked it may not be used in
hazardous areas.
Set-up Installation, mounting and adjustment of this product may only be executed
by skilled employees.
Installation Only mounting devices and accessories specifically provided for this product
may be used for installation.
Unused outputs may not be connected. Unused strands of hard-wired
sensors must be isolated. Do not exceed the maximum permissible bending
radius of the cable. Before connecting the product electrically the system
must be powered down.
Where screened cables are mandatory, they have to be used in order to
assure EMI protection. When assembling connectors and screened cables
at customer site the screen of the cable must be linked to the connector
housing via a large contact area.
