24
Jeppesen Workboat Navigator Installer’s Guide
2
-
Installation
2
-
Installation
VTG Track Made Good and Ground Speed
WCV Waypoint Closure Velocity (Velocity Made Good)
WDC Distance to Waypoint
WDR Waypoint Distance, Rhumb Line
WNC Distance - Waypoint to Waypoint
WNR Waypoint to Waypoint Distance, Rhumb Line
WPL Waypoint Location
XTE Cross Track Error, Measured
XTR Cross Track Error - Dead Reckoning
ZDA Time & Date
Table 2.7 - Supported Device Output
DEVICE IDENTIFIERS
DE DECCA Navigation
EC Electronic Chart Display
ER Engine Room Monitoring System
GP Global Positioning System
II Integrated Instrument
LA Loran A
LC Loran C
RA Radar and/or ARPA
SN Electronic Positioning System
TR Transit
Table 2.8 - Device Identifiers
Testing the Connection
When you have connected one or more hardware devices to your computer,
you need to test the connections to verify that Jeppesen Workboat Navigator is
receiving NMEA data sentences from them. Jeppesen Marine provides a Port Test
tool (Start | All Programs | Jeppesen Marine | Port Test) to test connections.
There are 4 links in the Port Test used to attempt to connect to COM Ports 1
through 4 using Window's HyperTerminal program.
Many computers may have more than 4 COM Ports, specifically when using a
Serial-to-USB port adapter. Use the System Menu | Tools/Settings | Options |
Ports: Configure: View Data button to verify the data that is being received by
each additional COM Port.
