FORD 2015 F-150 - Manual (Page 298)

Protected components Fuse amp rating Fuse or relay number
Not used. 10A 7
Not used. 10A 8
Not used. 10A 9
Not used (spare). 5A 10
Combined sensor module. 5A 11
Climate head module. 7.5 12
Smart datalink converter.
Cluster. 7.5A 13
SCCM.
Brake. 10A 14
Smart datalink converter. 10A 15
Tailgate release. 15A 16
HUD. 5A 17
Ignition switch and passive-entry passive-
start start stop switch. 5A 18
Key inhibit solenoid.
Tow haul (O/D) cancel for floor or column
shifter. 7.5A 19
Not used. 7.5A 20
HUD. 5A 21
In car temperature with humidity sensor.
EPB. 5A 22
Power seat.
PDRG switch. 10A 23
Inverter.
Driver side window.
Moonroof.
Central lock/unlock. 20A 24
Driver door control module. 30A 25
Passenger door control module. 30A 26
Vista roof. 30A 27
295
F-150 (), enUSA, First Printing
Fuses
