WARNINGS
Be sure the ramp is installed
correctly when loading and
unloading equipment on and off the
ramp.
Do not step or sit on the ramp when
it is in the stowed position.
Install the ramp only within the
prescribed ramp angles.
Note: The ramp maximum capacity is
800 lb (363 kg).
Note: Verify the ramp is on stable ground
before usage.
Note: For loading and unloading
equipment, your ramp should be set
between 10° upward and 26° downward to
avoid damage to the ramp claw and tailgate
plate.
Using the Bed Ramp
1. Remove the front and rear cables.
E194380
2. Open the cam lever arms and unscrew
the cam bolts.
3. Remove the ramp from the ramp
holder.
E194381
4. Rotate the stops at the underside of
the ramp to the open position.
E194382
5. Slide the ramp claw onto the tailgate
plate.
247
F-150 (), enUSA, First Printing
Load Carrying
