Engine Oil
If it illuminates with the engine
running or when you are driving,
this indicates a malfunction.
Stop your vehicle as soon as it is safe to
do so and switch the engine off. Check the
engine oil level. See Engine Oil Check
(page 302).
Note: Do not resume your journey if it
illuminates despite the level being correct.
Have the system checked by your authorized
dealer immediately.
Fasten Safety Belt
It will illuminate and a chime will
sound to remind you to fasten
your safety belt.
Four-Wheel Drive Indicators
(If
Equipped)
Note: Some indicators will appear different
depending on vehicle options.
4X2
E163173
E181778
Illuminates momentarily when you select
two-wheel drive high.
4X4 Auto
E181781
Illuminates when the four-wheel drive
system is engaged.
4X4 LOW
E163174
E181780
Illuminates when four-wheel drive low is
engaged.
4X4 HIGH
E163175
E181779
Illuminates when four-wheel drive high is
engaged.
Front Airbag
If it fails to illuminate when you
start your vehicle, continues to
flash or remains on, it indicates
a malfunction. Have the system checked
by an authorized dealer.
Front Fog Lamps
(If Equipped)
It will illuminate when you switch
the front fog lamps on.
High Beam
Illuminates when you switch the
high beam headlamps on. It will
flash when you use the
headlamp flasher.
Hill Descent
(If Equipped)
E163171
Illuminates when hill descent is
switched on.
102
F-150 (), enUSA, First Printing
Instrument Cluster
