Transmitter Power ON/OFF

The button on the right side of the

transmitter is the “ON/OFF” button that
activates the transmitter and LCD screen only.

To turn the transmitter on, press the

“ON/OFF” button on the right side until the
LCD screen illuminates.

To turn the transmitter off, press the

“ON/OFF” button on the right side of the
transmitter. When the LCD screen displays
“OFF” release the button.

24

BUTTON FUNCTION

25

DESCRIPTION OF COLLAR / RECEIVER PARTS

DESCRIPTION OF
COLLAR / RECEIVER PARTS

On/Off Magnetic Switch
(Red Dot)

Contact Points

Indicator Light

(LED Window)

Battery Charging
Receptacle
and Cover

Collar strap
