18
DESCRIPTION OF TRANSMITTER PARTS
Transmitter Battery Charging Receptacle &
Rubber Plug
Located on the backside of the transmitter,
the charging receptacle is covered by a rubber
plug. Insert one end of the battery charging cable
into the receptacle to charge the battery.
(See Battery Charging Procedure on page 38~40.)
After charging is completed, close the
receptacle with its rubber plug to make sure dirt
or water does not get inside.
The unit will be fully waterproof with or
without the rubber plug.
19
BUTTON FUNCTION
The transmitter for the
has five buttons.(two on the face of the
transmitter, two on the left side, and one on
the right side.)
“Nick” Button
When the “Nick” button is pushed, the
receiver emits a single rapid pulse of electrical
stimulation.
BUTTON FUNCTION
Lccate
Nick
Beeper Sound
Toggle Switch
ON/OFF
Switch
Mode
Constant
