CTEK Z4300U SkyRouter User Manual
Page 23
22 September 2009
20
4.2 Services
4.2.1 Password
Administration
Used to change passwords and create users. Be sure to record this information in a secure location.
Figure 16
4.2.2 Routing and Forwarding Services
The Routing and Forwarding Services screen provides two separate but related functions. First it allows you to forward
WAN side IP traffic arriving on a specific IP Port to a specific Port at a LAN side address. In addition to this conventional
forwarding feature this screen also allows you to make a Named Service publicly available over the WAN interface. In
Figure 17 below WAN side UDP and TCP traffic arriving on Port 88 is redirected to Port 80 of LAN address
192.168.1.102.
The second function performed by this set up screen to allow named services to be made publicly available to WAN side
users. Referring again to Figure 17 a service named “Ctek SkyRouter Demo – San Pedro, CA” will be advertised or made
publicly available. Security for this advertised service is left up to the specific service. If the Advertising feature is used the
Administrative Login screen will no longer greet incoming WAN users, instead they will be presented with a Services
screen as shown in Figure 18.
