Carrier – Often referred to as the Mobile Operator
Network Status – Possible values are “In Service”, “No Service”, or “Service Denied”. Indicates the state of the network
as seen through your particular router
Service Type – Indicates whether EGPRS (EDGE) is available or failing that whether GPRS is available. Possible values
are “None”, “EGPRS”, or “GPRS”.
Current IP Address – The Internet Protocol (IP) address assigned to this router by the serving wireless network. If this
field is blank a connection does not currently exist.
Signal Level (RSSI) – A measure of the strength of the wireless signal that your router is currently seeing. A larger
negative number indicates a marginal network connection. Typically this number will be in the range of -75 - -95dBm
although there are many locations where the value will be outside of the typical range.
Roam Status – Indicates the network’s view of the current geographic location of your router. The possible values are
“Not Roaming”, or “Roaming”. An indication of Roaming may or may not impact your data transmission costs. Charges
are a function of your rate plan, not necessarily linked to the networks notion of roaming.
Call Status – Indicates the current status of network registration. Possible values are “Attached”, or “Not Attached”.
Subscriber ID (IMSI) – Identifies the subscriber. IMSI is contained in the SIM.
Equipment ID (IMEI) – Identifies a particular piece of hardware, specifically the radio within the SkyRouter
Radio Type – Displays the Radio Manufacturer
Firmware Rev. – Displays the firmware revision level of the radio.
Phone Number (MSISDN) – The network address of the unit
Short Message Service Center Address. - A number prefixed with a plus (+) sign that specifies the service center that
will handle SMS traffic. Provided by the network operator.
Model – The model number of the radio installed.
Hardware Rev. – If available displays the revision level of the radio module
