Bio-Rad PowerPac™ Universal Power Supply - Manual (Page 8)

2
The PowerPac Universal has the following features:
• Constant voltage, constant current, or constant power operation with automatic
crossover
• LCD screen displays all run parameters at once
• Programmable methods with up to nine steps
• Storage capacity for up to nine user defined methods
• Continuous, hour and volt-hour time modes
• Paused run editing
• Safety features: no-load, short circuit, rapid resistance change, ground leak,
and internal thermal protection
• User optional run completion after an AC power failure
• Adjustable LCD display contrast
• EN61010 international safety certification
• Input power 100-120/220-240 VAC, 50/60 Hz, auto-switching
• Four output terminals
• Stackable case with adjustable viewing angle via flip down legs (See Figure 3)
• Infrared port, for transmitting data to a personal computer or PDA
Optional:
• Data transfer software (DTS) for data file management on a PDA and PC
Fig. 3. Front view with legs in lowered position.
LEGS
(LOWERED POSITION)
