2 - 14
BLUE HYDRAULIC DRIVE PUMPS
DESCRIPTION
The Reversible Hydraulic Drive Pump has a small high speed pump
driven by a 12 or 24V DC permanent magnet motor. The pump has pilot
check valves to prevent back driving and a pilot operated reservoir
valve to enable the unit to drive balanced or unbalanced cylinders. The
unit has Port and Starboard 1/4" BSP service ports and a 1/4" BSP
reservoir port.
PUMP DATA
HYDRAULIC PUMP
TYPE PMP-T1-12V PMP-T2-12V PMP-T3-24V
PUMP TYPE Reversible
DC motor Reversible
DC motor Reversible
DC motor
SUPPLY VOLTAGE 12V DC 12V DC 24V DC
TYPICAL OPERATING
CURRENT RANGE 5 to 17.5 Amps 5 to 22.5 Amps 6 to 17.5 Amps
MAXIMUM PRESSURE 1000 psi 1000 psi 1000 psi
MAXIMUM FLOW RATE
at continuous duty motor
loading 750 cc/min,
46 ins3/min 1420 cc/min,
87in3/min 1980 cc/min,
121 in3/min
CYLINDER CAPACITY 100-300cc,
6.1 to 18.3 in3 275 to 550cc,
16.8 to 33.6in3 525 to 750cc,
32 to 46in3
WEIGHT 3 kg
6.6 lbs
3 kg
6.6 lbs 4 kg
8.8 lbs
