5 - 31
SELECTING POWER STEER MODE
1. With the autopilot in standby, STBDY.
2. Select the commissioning mode by pressing AUTO and OFF keys
together.
3. Turn the wheel so the rudder is in the midships position (if possible).
Press
SETUP
key, select
POWER. With the
rudder
amidships.
Press
AUTO key
to engage
power
steer. Use the
<10 or 10>
keys to
move the
rudder 3º
to port or
starboard
for each
press. Use the <1
or 1> keys
to move
the rudder
0.6º to port
or
starboard
for each
press.
NOTE: When the AUTO key is pressed the rudder will return to the
position it was in when POWER steer was engaged. If the rudder was
set at the midships position then pressing the AUTO key will return it to
that position.
