6 - 8
TRIP CURRENT TRIP
Fault description:
The voltage/current limit circuit for the drive motor or the clutch has
tripped.
ACP1 12V Drive Motor - 15A Clutch - 2A
ACP2 12/24V Drive Motor - 25A
Clutch - 2A
Check list:
1. Check installation and wiring for short circuits.
2. Check current to clutch, maximum available 2 amps.
3. Check maximum current to drive motor is less than above.
ERR 17 NETWORK DATA ERROR
Fault description:
No regular messages being received by the Pilot Display or instrument
system network, i.e. either the display is not transmitting or receiving
network messages.
Check list:
1. If other displays show Pilot data, check installation and operation of
Pilot display.
2. If Pilot responds to commands from other displays then Pilot
computer is operating correctly.
3. Check installation of network cable.
NO PILOT PILOT DISPLAY
Fault description:
No regular messages being received by pilot display from pilot control
via instrument system network, i.e. either the display is not receiving or
the Pilot computer is not transmitting.
