H5000 Central Processor Unit - CPU |
H5000 Installation
Digital output (Alarm)
1
2
3
4
Color
Description
1
-
-
2
-
-
3
Sensor
Dependent
Output
4
Sensor
Dependent
0 Volts
1
2
3
4
+
12 Volts
0 Volts
-
NMEA 0183 - Channel 2
1
2
3
4
Color
Description
1
Sensor
Dependent
TX_A ( - )
2
Sensor
Dependent
TX_B (+)
3
Sensor
Dependent
RX_A ( - )
4
Sensor
Dependent
RX_B (+)
