5317-5323 Wing Fold Cylinders
Refer to Figure 14
78. Install wing fold bracket
to wing frame with 3/4 x 6
hex bolts , 3/4 lock washers and 3/4 nuts.
79. Attach base end of the 4 x 30 fold cylinders to cen-
ter fold bracket with 1 x 3 3/8 pins , 1.5 x 1.0 x.075
machine washer and 3/16 x 2 cotter pin.
Note: Do not attach rod end of the fold cylinders to
wing cylinder brackets until fold cylinders have
been purged of air, See “Purging Hydraulic Sys-
tem” on page 28.
80. Tighten all bolts to specs, See “Torque Values
Chart” on page 31.
