8 TC5109-5323 Great Plains Manufacturing, Inc.
566-224Q-ENG 03/06/2014
Center Lift & Gang Mount
Refer to Figure 7
21. Attach the cylinder mount bars
and lift link to
center frame using 1 x 3 1/2 hex bolts , 1 x 4 hex
bolts and 1 lock nuts.
22. Now install 4.5 x 10 cylinders using 1 x 3 1/8 pins
, 1.5 x 1.0 x.075 machine washers and 3/16 x 2
cotter pins.
23. Install cylinder transport locks to cylinder mount
bars using the 5/16 wire retainer pin .
24. On models 5111-5115 fasten wings to center
frame with 3/4 x 2 1/2 hex bolts , 3/4 lock washers
and 3/4 nuts.
Note: Wing shank mounts are only used on a few
models, see machine and attachment layout draw-
ings in Appendix for proper placement.
25. Attach outside wing shank mounts (if equipped)
with 3/4 x 2 1/2 hex bolts 3/4 lock washers and 3/
4 nuts.
26. Attach center gang mount and wing gang mounts
to front of center frame and wing frame with 3/4 x
2 hex bolts , 3/4 lock washers and 3/4 nuts.
Note: See machine layout section for proper light
bracket placement.
27. Fasten light bracket LH to center frame with 1/2 x
4 1/32 x 7 1/4 u-bolts , 1/2 lock washers and 1/2
huts. Repeat same procedure for light bracket RH
.
28. All bolts may be tightened to specs, See “Torque
Values Chart” on page 31.
1 2
3
4
5
6
7
1 8
9
10
11
11
10
12
13
14
15
17
16
