14 TC5109-5323 Great Plains Manufacturing, Inc.
566-224Q-ENG 03/06/2014
5109-5315 Center Fold
Refer to Figure 10
50. Install center fold bracket
and rebound valve
bracket to front center frame plate with 3/4 x 2 1/2
hex bolts , 3/4 lock washers and 3/4 nuts.
51. Attach center wing stop (Models 5313 & 5315
only) to truss plates with 5/8 x 1 1/2 hex bolts , 5/8
lock washers and 5/8 nuts.
52. Attach bolt on wing pivots on side of center frame
with 3/4 x 2 1/4 hex bolts , 3/4 lock washers and 3/
4 nuts.
53. Attach 12ga 16ga shim’s as needed with 3/4 x 1
1/2 hex bolts , 3/4 lock washers and 3/4 nuts to
level wings.
Note: See “Operator’s Manual” general operation and in-
field adjustment section for adjustment procedure.
Store extra shims in manual pak
.
54. Models 5109-5115 attach rigid smv & light bracket
to rear truss plates with 5/8 x 1 1/2 hex bolts ,5/
8 lock washers and 5/8 nuts.
55. Attach SMV sign to either center wing stop or
rigid smv & light bracket with 1/4 x 3/4 pan head
screws , 1/4 lock washers and 1/4 hex nuts.
56. Models 5313-5315 attach rebound valve with 5/
16 x 4 hex bolts , 5/16 lock washers and 5/16 nuts.
57. Attach double block tee with 5/16 x 3 1/2 hex bolts
, 5/16 lock washers and 5/16 nuts.
58. Tighten all bolts to specs, See “Torque Values
Chart” on page 31.
1
2
3
4
5
6
7
8 9
10
11
12 5
13 4
12
14
15
16
18
19
