Great Plains TC5319 (S/N A1420X+) Assembly Manual - Manual (Page 14)

10 TC5109-5323 Great Plains Manufacturing, Inc.
566-224Q-ENG 03/06/2014
Trusses
Refer to Figure 8
Note: Do not tighten any bolts until all parts are assem-
bled.
29. Start by bolting the rear of the LH and RH
trusses to center frame using 1 1/4 x 8 1/2 Gr. 8 hex
bolts
, 1 1/4 lock washers and 1 1/4 nuts. Attach
middle plates of trusses with 3/4 x 2 1/2 hex bolts ,
3/4 lock washers, 3/4 nuts, front plates with 3/4 x 2
3/4 lock washers, and 3/4 nuts.
30. Mount the manual pack to RH truss plate with 1/
4 x 1 hex bolts , mini end press wheels , 1/4 lock
washers and 1/4 nuts.
31. Models 5317-5323, attach the bypass valve to the
RH truss with 5/16 x 3 hex bolts , 5/16 lock
washers and 5/16 nuts.
32. Models 5317-5323, install the rebound valve plate
with two 3/4 x 3 hex bolts , 3/4 lock washers, 3/4
nuts.
33. Models 5317-5323, install the pilot operated check
valve to rebound valve plate with 5/16 x 2 hex
bolts , 5/16 lock washers, 5/16 nuts
34. All bolts may be tightened to specs, See “Torque
Values Chart” on page 31.
