Refer to Figure 11
59. Install center fold brackets
to center frame plates
with 3/4 x 2 hex bolts , 3/4 lock washers and 3/4
nuts.
60. Attach center wing stop to truss plates with 5/8 x 1
1/2 hex bolts , 5/8 lock washers and 5/8 nuts.
61. Attach bolt on hinge on side of center frame with
3/4 x 2 1/2 hex bolts , 3/4 lock washers and 3/4
nuts.
62. Attach SMV sign to center wing stop with 1/4 x
3/4 pan head screws , 1/4 lock washers and 1/4
hex nuts.
63. Attach double block tee on both front and rear
center fold brackets with 5/16 x 3 1/2 hex bolts , 5/
16 lock washers and 5/16 nuts.
64. Tighten all bolts to specs, See “Torque Values
Chart” on page 31.
