12 TC5109-5323 Great Plains Manufacturing, Inc.
566-224Q-ENG 03/06/2014
Hitch & Center Lift Assembly
Refer to Figure 9
35. Attach hitch pole
to trusses using 1 1/4 x 8 Gr. 8
hex bolts , 1 1/4 flat washers (one on each side
of uni-ball) and top lock nuts. Washers are needed to
ensure a tight fit. Bolts need tightened securely, but
do not over-tighten as the hitch needs to pivot.
36. Mount square jack to front mount on hitch with
pin provided with jack. Use jack to help support front
of hitch for rest of hitch assembly.
37. The front of the hitch turnbuckle may be attached
to the hitch pole ears with 1 x 3 5/8 clevis pin , 1.5 x
1.0 x.075 machine washers and 3/16 x 2 cotter pins.
38. Attach bottom hole of hitch leveling arm to ears on
back of hitch pole with 1 x 7 Gr. 8 hex bolts and
1 lock nuts
39. Attach the back of the hitch turnbuckle to the top
ears of hitch leveling arm , turnbuckle lock and
level bar with 1 1/4 x 9 special thread hex bolt
and 1 1/4 lock nut. Attach the 3/8 x 4 pin wire snap
lock
to the turnbuckle lock.
40. Attach front holes of h-bracket to rear of level bar
with 1 x 4 hex bolts , and 1 lock nuts.
41. Attach middle holes of h-bracket to top holes of lift
straps and bottom holes of lift straps to ears on
torque tube with 1 x 3 1/2 hex bolts , and 1 lock
nuts.
42. Attach rear holes of h-bracket to ears on center
frame with 1 x 3 1/2 hex bolts , and 1 lock nuts.
43. Align holes in safety chain support , cat III hitch
tongue with holes on left side of hitch pole ,
secure with 1 x 8 Gr. 8 special hex bolts , four, 1
SAE flat washers , lock washers and 1 nut.
44. Install safety chain on bottom side of hitch pole ,
secure with 7/8 x 3 hex bolt , 7/8 flat washer , 7/
8 lock washer and 7/8 nut.
45. Attach hitch clevis to cat III hitch tongue with 3/
4 x 5 1/2 Gr. 8 hex bolt and 3/4 lock nut.
Note: Do not use hitch clevis if tractor has a hammer
strap. Use for transporting with truck.
46. Route safety chain through safety chain support
.
47. Attach hose holder to nut on front hitch pole
with 1/2 x 1 hex bolt ,1/2 flat washer and 1/2 lock
washer.
48. Attach counterbalance valve to the plate on front
of hitch pole with 5/16 x 3 1/2 hex bolts and 5/
16 lock washers.
49. All bolts may be tightened to specs, See “Torque
Values Chart” on page 31.
1
2 3
4 1
5
6
7
1 8
5
7 9
11 12
10
13
11 15
13
14 14
16
13
16
17
18 1
19
20
21 1
22 23
24 18
25
24
21
17
26 1
22
28
1 29
