Removing a Seed Disk
Refer to Figure 110
1.
Remove rain cover. If seed is present, close
shutter
to prevent more seed from entering meter.
Attach funnel (page 99).
2. Hold seed disk in meter. Rotate disk clamp
counterclockwise 45
° to release disk.
3. Tilting top of disk toward meter, slowly remove disk,
allowing seed to collect in funnel. Open shutter to
release remaining seed up to wing tube.
4. Clean seed from all brushes. Clean disk seat ( in
Figure 107 page 78), so that new disks can seat fully.
Inspect brushes for excess wear and damage. See
“Meter Brush Maintenance” on page 101.
5. Inspect removed disks for excess wear and damage.
Set aside any disks requiring replacement. Clean
other removed disks and place in storage. See
“Seed Disk Maintenance” on page 103.
6. Re-install the rain cover (page 76).
Row Unit Shut-Off
Skip-row operations, such as planting from every other
row when switching from 30 inch twin-row to 30 inch
single-row, requires shutting down unused rows.
Shutting off seeding at a row involves 4 to 7 steps:
1. Identify the rows to shut off.
2. Fully close seed inlet shutter (always done).
3. Replace seed disk with blank disk (always done).
4. Close seed flow to row at Y-tube (if present).
5. Lock up row unit to reduce wear (optional).
6. Reset marker extension (if used, page 54).
7. Reset monitor active row pattern and row spacing to
avoid nuisance alarms (always done).
Note: Meter drive is not disabled on 25AP row units
during shut-off.
Figure 110
Remove Disk
29611
3
1
4
4
1
2
Figure 111
Seed Inlet Shutter Closed
29609
2
1
