18 YP2425A Table of Contents Index Great Plains Manufacturing, Inc.
401-626M Table of Contents Index 2014-02-10
Store Main Parking Stand
Refer to Figure 9 and Figure 10
1.
Remove the lower pin and the upper pin
holding the parking stand .
2. Move the stand from under the tongue to an inverted
position in the bracket on the left side on the tongue.
Raising/Lowering Tongue
In addition to hitching, tongue raising and lowering is
required during fold and unfold to engage and disengage
the wing locks.
With the standard 3-point hitch, the planter tongue is
raised and lowered by raising and lowering the 3-point.
With the optional hydraulic tongue, the planter tongue is
raised by extending the hitch cylinder, and lowered by
retracting the hitch cylinder.
Figure 9
Main Parking Stand
26110
2
1
3
1 2
3
Figure 10
Parking Stand Stored
29242
3
