Twin-Row Model Specifications
Model
3P4025AH 3P4025AH 3P4025AH 3P4025AH
-24TR36 -24TR38 -24TR40 -32TR30
Row Count 24 Rows, 12 Pairs 32 Rows, 16 Pairs
Row Spacing
36 inches 38 inches 40 inches 30 inches
(91.4 cm) (96.5 cm) (101.6 cm) (76.2 cm)
Frame Width 38 ft. 9 in. (1181.1 cm)
38 ft. 7 in.
(1176.0 cm)
Swath
432 inches 456 inches 960 inches 480 inches
(1097.3 cm) (1158.2 cm) (2438.4 cm) (1219.2 cm)
Transport Width 24 ft. 3 in. (739.1 cm)
25 ft. 1 in.
(764.5 cm)
Working Length (Max.) 155.0 inches (393.7 cm)
Working Height 7 feet 1 inches (215.9 cm)
Transport Height 12 feet 8 inches (3.86 m) with 8 in. (20 cm) coulter clearance in transport
Minimum Tractor Req. 260 - 300 hp (195 - 225 kW)
290 - 330 hp
(215 - 245 kW)
Hitch 3-Point Category III Wide or IV Wide, Category III Narrow
Tool Bar 7 7 3/8 inch (18 18 1 cm)
Hydraulic Circuits Closed-Center or Open-Center , 2, 3 or 4 Remotes
Hydraulic Power Required 2250 psi, 15 gal/min (155 bar, 57 litres/min)
Typical Weight, Empty 16,100 pounds (7300 kg)
18,400 pounds
(8350 kg)
Wing Flex 7.5 Up and Down
Row Down Pressure 350 to 540 pounds (159 to 245 kg)
Row Travel (Up - Down) 5 inches up and down (+13 cm; -13 cm)
Opener Depth 4.0 inch (10.2 13 mm)
Gauge wheel Tires 7.60-15 6-Ply Lug
Lift-Assist Tires (Option) 380/55R-16.5 Load Rating F
2. Hydraulic down-pressure option requires closed-center or pressure compensated flow open-center tractor system.
3. Minimum. With hydraulic down pressure, requirements increase to 2250 psi, 20 gal/min (155 bar, 76 litres/min)
Applicable to Hydraulic Down-Pressure and Hydraulic Down-Float options only.
