Appendix A - Reference Information
Specifications and Capacities
Single-Row Models Specifications
Model
3P4025AH 3P4025AH 3P4025AH 3P4025AH
-1236 -1238 -1240 -1630
Row Count 12 Rows 16 Rows
Row Spacing
36 inches 38 inches 40 inches 30 inches
(91.4 cm) (96.5 cm) (101.6 cm) (76.2 cm)
Frame Width 38 ft. 9 in. (1181.1 cm)
38 ft. 10 in.
(1183.6 cm)
Swath
432 inches 456 inches 480 inches 480 inches
(1097.3 cm) (1158.2 cm) (1219.2 cm) (1219.2 cm)
Transport Width 24 ft. 3 in. (739.1 cm)
Working Length (Max.) 155.0 inches (393.7 cm)
Working Height 7 feet 1 inches (215.9 cm)
Transport Height 12 feet 8 inches (3.86 m) with 8 in. (20 cm) coulter clearance in transport
220 - 250 hp (165 - 185 kW)
230 - 260 hp
(170 - 195 kW)
Hitch 3-Point Category III Wide or IV Wide, Category III Narrow
Tool Bar 7 7 3/8 inch (18 18 1 cm)
Hydraulic Circuits Closed-Center or Open-Center , 2, 3 or 4 Remotes
2250 psi, 15 gal/min (155 bar, 57 litres/min)
Typical Weight, Empty 12,500 pounds (5670 kg)
13,700 pounds
(6210 kg)
Wing Flex
7.5 Up and Down
Row Down Pressure 350 to 540 pounds (159 to 245 kg)
Row Travel (Up - Down) 5 inches up and down (+13 cm; -13 cm)
Opener Depth 4.0 inch (10.2 13 mm)
Gauge wheel Tires 7.60-15 6-Ply Lug
Lift-Assist Tires (Option) 380/55R-16.5 Load Rating F
1. 2-Point with Lift-Assist
2. Hydraulic down-pressure option requires closed-center or pressure compensated flow open-center tractor system.
3. Minimum. With hydraulic down pressure, requirements increase to 2250 psi, 20 gal/min (155 bar, 76 litres/min)
Applicable to Hydraulic Down-Pressure and Hydraulic Down-Float options only.
Minimum Tractor Req.
Hydraulic Power Required
