Seed Flap Replacement
Current Solid Flap Replacement
Refer to Figure 105
To replace a seed flap , use needle nose pliers or
similar tool to grasp “T” top of flap. Pull upward to remove
flap from metal bracket
.
Push new seed flap down through metal bracket until flap
snaps into place with “T” top resting on top of bracket.
If a seed firmer is also installed, it may be necessary to
shorten the flap.
Older Split Flap Replacement
Refer to Figure 106
To replace an older split-style seed flap use a needle
nose or similar tool and squeeze the tabs together.
Pull plastic seed flap down out of metal bracket .
Push new seed flap up through metal bracket until
tabs on seed flap snap in place.
Figure 105
Solid Seed Tube Flap
19398
1
2
1
2
Figure 106
Split Seed Tube Flap
18398
5
4
3
4
3
4
3 5
3 5
4
