TECHNICAL SUPPORT: 1.800.283.5936 (USA) OR 1.801.974.3760
C
DIMENSIONS
17"/43.2cmW x 1.75"/4.5cmH x
8"/25.4cmD
WEIGHT
7 lb/3.18 kg (dry)
12 lb/5.4 kg (shipping)
REAR PANEL CONNECTORS
POWER:
IEC Type
Auto-adjusting power module from
100–240 VAC, 50/60Hz, 15W (typical)
REMOTE: DB25 female connector.
Remote Transmit Input:
0dBu nominal, unbalanced 10kOhm
impedance
Remote Receive:
0dBu nominal, unbalanced, 50 Ohm
impedance
Control Inputs:
Remotely activate functions with a
momentary switch closure to ground
Status Outputs:
Remotely check the status outputs.
Status outputs are open collector out
puts rated at 30VDC and 40mA maxi-
mum.
RS-232: DB9 female
9600, 8 bits, 1 stop bit, no parity
TRANSMIT INPUT:
Push-on terminal block with slotted set-
screw connectors contacts provided at
terminal block at +20dBm maximum input,
0dBu nominal level, balanced bridging
>20kOhm impedance
RECEIVE OUTPUT:
Push-on terminal block with slotted set-
screw connectors contacts provided at
terminal block at +20dBm maximum input,
0dBu nominal level, <50 Ohm impedance
TELCO LINE: RJ-11 connector
POTS (plain old telephone service)
telephone line or analog extension from a
PBX. A-Lead Supervision provided
TELCO SET: RJ-11 connector
A-Lead Supervision provided
FRONT PANEL CONNECTORS
CONTROLS:
On Button
Off Button
STATUS LEDS:
Transmit Audio Presence
Receive Audio Presence
Appendix C
Specifications
APPENDIX C • SPECIFICATIONS 25
