APPENDIX B
• PINOUTS
Set Connector Pinout
Pin
Description
Pin
Description
1
To pin 6 of SET RJ-11C
4
Tip
2
To pin 5 of SET
5
To pin 2 of LINE
3
Ring
6
To pin 1 of LINE RJ-11C
Line Connector Pinout
Pin
Description
Pin
Description
1
To pin 6 of LINE RJ-11C
4
Ring
2
To pin 5 of LINE
5
To pin 2 of SET
3
Tip
6
To pin 1 of SET RJ-11C
