INSTRUCTIONS FOR CHANGING INDICATOR SLIDES
1. REMOVE PHILIPS SCREW.
2. REMOVE BACK PLATE, HUB PLATE AND SLIDE.
3. REPLACE WITH ALTERNATE SLIDE.
NOTE: CHECK FOR PROPER ORIENTATION OF VAC/OCC
SLIDE TEXT.
4. REASSEMBLE HUB PLATE AND BACK PLATE, SECURE WITH
PHILIPS SCREW.
Item
Description
Qty.
Part
Number
1
Indicator Housing
1
82-0604
2
Spindle Hub
1
82-0605
3
Spindle
1
77-1195
4
Red/White Slide
1
82-4050
VAC/OCC Slide
1
82-4051
5
Hub Plate
1
82-0590
6
Back Plate
1
82-0606
7
#6-32 x 3/16” MS
1
01-4553
8
Mounting Adapter
1
91-2151
9
Mounting Post, 185S-1, 1-3/8” Door
2
81-0017
Mounting Post, 185S-2, 1-3/4” Door
2
81-0723
Mounting Post, 185S-3, 2” Door
2
92-0069
Mounting Post, 185S-4, 2-1/4” Door
2
82-0539
10
TORX Screw
1
01-1421
