6.1.7 Trip Information screen
The Trip Information screen has both route and
travel data you might need during your journey. It
can be opened directly from the Map screen by
tapping the Trip Data field ( ).
The fields on this screen are continuously updated
while you keep the screen open.
When you open the screen, all route data fields
contain information about reaching your final
destination. Tap
and the fields
concerning your route display data for the next via
point. Tap the button repeatedly to toggle between
the two options.
You have the following data and functions on this screen:
Name Description Function
or
Shows whether the route data fields show
information about the final destination (checkered
flag) or about the next via point (yellow flag) .
Field next to
the flag Shows the name or number of the current street or
road.
Turn Preview Shows the type and distance of the next route event.
Name Description Function
Warning
icons
In these square fields graphical symbols are displayed in
case warnings are attached to the planned route. These are
warnings, so icons always show information for the whole
route, even if the data fields display values from your current
position to a via point only.
Tap any of the icons for an
explanation.
Opens the Route Planning
options screen from
theSettings menu.
Opens the map screen
designed for route planning.
Appears only if at least one via point exists.
Deletes the next via point from
the route.
Appears only if there are no via points in the route. Deletes the active route.
