NP401 43
During navigation, the screen shows route
information and trip data (left screenshot), but when
you tap the map, additional buttons and controls
appear for a few seconds (right screenshot). Most
parts of the screen behave as buttons.
Symbol Name Action
Turn Preview, that is, the
next route event
Opens the Route Information screen
Second upcoming route
event
Opens the Itinerary
Trip data Opens the Trip Information screen
GPS position quality Opens the Quick menu
Vehicle used in route
calculation
Opens the Quick menu
Top row Next street or Next city Additional buttons and controls appear for a few seconds
Bottom row
Current street and house
numbers on left and right
Additional buttons and controls appear for a few seconds
,
, Map view modes
Switches between 2D and 3D map modes:
• 2D North-up
• 2D rotated
• 3D rotated
Menu Opens the Navigation menu
Detour
Opens the Detour screen, offering two ways of modifying the
route:
• the list of Saved Search Criteria
• a button to avoid parts of the route
