CY7C1364C
Document #: 38-05689 Rev. *E Page 15 of 18
ZZ Mode Timing
[22, 23]
Notes:
22. Device must be deselected when entering ZZ mode. See Cycle Descriptions table for all possible signal conditions to deselect the device.
23. DQs are in High-Z when exiting ZZ sleep mode.
Switching Waveforms (continued)
t
ZZ
I
SUPPLY
CLK
ZZ
t
ZZREC
ALL INPUTS
(except ZZ)
DON’T CARE
I
DDZZ
t
ZZI
t
RZZI
Outputs (Q)
High-Z
DESELECT or READ Only
