14
pa r t s l i s t
F O R C E D A I R E L E C T R I C H E AT E R S
PART NUMBERS
Please have model and serial number available
before calling
item 2.5 - 4.6 kW 6.3 - 10 kW 12.5 - 20 kW 20.9 - 35 kW description
1 ** ** ** ** Core
2
Painted: 9203
S.S.: 9507
Painted: 9204
S.S.: 9508
Painted: 9205
S.S.: 9509
Panel, Bottom
3
Painted: 9191
S.S.: 9192
Painted: 9193
S.S.: 9194
Painted: 9195
S.S.: 9196
Panel, Left Side
4 4075 4076 4077 Louver Kit, c/w screws
5
Painted: 9200
S.S.: 9513
Painted: 9201
S.S.: 9514
Painted: 9202
S.S.: 9515
Panel, Top
6
Painted: 9197
S.S.: 9510
Painted: 9198
S.S.: 9511
Painted: 9199
S.S.: 9512
Panel, Right
7
Painted: 3782
S.S.: 9212
Painted: 3783
S.S.: 9213
Painted: 3784
S.S.:9214
Panel, Fan Shroud
8 4022 4023 4024 4025 Fan Blade
9
Painted: 4078
S.S.: 9504
Painted: 4079
S.S.: 9505
Painted: 4080
S.S.: 9506
Fan Guard Kit
10
12215
208/240V 1PH 60HZ
220V 1PH 50HZ
12224 N/A 480V 1PH 60HZ
10562
208/240/480V 3PH 60HZ
380/415V 3PH 50HZ
12216 600V 3PH 60HZ
11
Painted: 3789
S.S.: 9112
Painted: 3789
S.S.: 9112
Painted: 3789
S.S.: 9112
Bracket, Motor Mount Right
12
Painted: 3785
S.S.: 9206
Painted: 3786
S.S.: 9207
Painted: 3787
S.S.: 9208
Channel, Motor Mount
13
Painted: 3788
S.S.: 9111
Painted: 3788
S.S.: 9111
Painted: 3788
S.S.: 9111
Bracket, Motor Mount Left
14 3737 or 4590 (for 12224) Coupling, Motor
15 9500 9500 3813 10389 Conduit, Motor
16 5371 5371 5371 5371 Cover, Thermostat Enclosure
17 3813 3813 3813 3813 Conduit, Control Enclosure
18 9314 9314 9315 9316 Conduit, Element Enclosure
19 9679 9679 9679 9679 Enclosure, Element
20 3510 3510 3510 3510 Cover, Element Enclosure
21
Painted: 9354
S.S.: 9516
Painted: 9355
S.S.: 9517
Painted: 9356
S.S.: 9518
Panel, Element Enclosure Guard
22 4983 4983 4983 Enclosure, Thermostat
23 11495 Thermostat, Built-in-kit
24 - - - Enclosure, Control
25 3619 Contactor, 75A
26 10556 (60HZ) 11295 (50HZ) Transformer, 50VA Multitap
27 3809 3809 3809 3809 Bracket, Printed Circuit Board
28 1876 1876 1876 1876 Terminal, 6-14 Ga. Screw Lug
29 9357 9357 9357 9357 Fuse, Buss MDQ - 1/2 Amp
30 3514 3514 3514 3514 Assembly, Printed Circuit Board
31 11960 11960 11960 11960 Cover, Control Enclosure
32 12094 12094 12094 12094 Plate, Trip Breaker Mount
33 - - - - Trip Breaker
35 9289 9289 9289 9289 Plug, 1" NPT Explosion Proof
36 - - - - High-Limit Kit (N.O.) Red Leads
37 - - - - High-Limit Kit (N.C.) White Leads
38
Provided with Core Kits**
Bus-Bar, Straight
39 Bus-Bar, Small Curved
40 Bus-Bar, Large Curved
41 - - - - Kit, DS5 Assembly
**See technical data table for part numbers. NOTE: For items not shown, please contact factory.
