CCI Thermal Technologies CF1 - ProVector Explosion-Proof Convection Heater - Manual

OWNER’S MANUAL
CF1 ProVector
®
Series
Electric Convection Air Heaters for Hazardous Locations
APPROVED LOCATIONS
Electric convection air heaters have an
EC-Type Examination Certificate
Demko No. 02ATEX0152068X for Ex d IIB, IIC T2-T4 Gb
-45°C (-49°F) ≤ Ta ≤ 40°C (104°F)
0359 II 2 G IECEx UL 11.0020X
For Product Temperature Codes refer to
CF1 Technical Data Chart in this manual.
Equipment or Protective System Intended
for use in Potentially Explosive
Atmospheres Directive 94/9/EC.
Compliance with the Essential Health and
Safety Requirements has been assured by
compliance with:
EN 60079-0: 2009, EN 60079-1: 2007
IEC 60079-0: 2007, IEC 60079-1: 2007
Part No. 8409.Rev.9.02
Printed in Canada
Issue Date: August 2013
– 1 –
This manual covers installation, maintenance, repair and parts.
W A R N I N G !
READ ALL IMPORTANT NOTICES ON PAGE 3.
ProVector® and Ruffneck™ are registered trademarks.
Copyright© 2013. All rights reserved.
CF1 220 1 50 - 012 - T2 - IIB - T
MODEL CODING
KILOWATTS
0075 - 0.75kW 017 - 1.70kW 044 - 4.40kW
0083 - 0.83kW 018 - 1.80kW 048 - 4.80kW
009 - 0.90kW 023 - 2.30kW 053 - 5.30kW
010 - 1.00kW 025 - 2.50kW 057 - 5.70kW
011 - 1.10kW 027 - 2.70kW 064 - 6.40kW
012 - 1.20kW 030 - 3.00kW 070 - 7.00kW
013 - 1.30kW 033 - 3.33kW 076 - 7.60kW
014 - 1.40KW 036 - 3.60kW
015 - 1.50kW 040 - 4.00kW
MODEL SERIES
VOLTAGE
220V
230V
240V
254V
380V
400V
415V
PHASE
UNITS IN
SINGLE PHASE
ONLY
FREQUENCY
50 or 60 HERTZ
T-CODE
T2 - 300ºC (572ºF)
T3 - 200ºC (392ºF)
T4 - 135°C (275ºF)
HAZARDOUS
LOCATION
IIB
IIC
BUILT-IN
T'STAT
ADD 'T' FOR
T'STAT
TM
ISO 9001
POCC CA. ГБ06.B00913
