Fx5 sd series, Owner’s manual

Owner’s Manual
FX5 SD Series
Electric Forced Air Heaters for Hazardous Locations
This manual covers the installation, maintenance, repair and replacement parts.
FX5-SD - 4803 60 - 350
KILOWATT RATING
HERTZ
PHASE
VOLTAGE
SEVERE DUTY
5th GENERATION
MODEL SERIES
W A R N I N G !
READ ALL IMPORTANT INFORMATION NOTICES ON PAGES 2, 3 & 4.
M O D E L C O D I N G
Part No. 12212.Rev.1.02
Issue Date: January 2013
Printed in Canada
Ruffneck
™
and VacuCore® are registered trademarks of CCI Thermal Technologies Inc.
Copyright© 2013. All rights reserved.
APPROVED LOCATIONS
The Electric Forced Air Heaters are
c
UL
us
listed
certified for the following locations:
Class I, Divisions 1 & 2, Groups C & D;
Class II, Division 1, Groups E, F, & G;
Class II, Division 2 , Groups F & G;
Class I, Zones 1 & 2, Groups IIA & IIB;
Temperature Code T3B 165˚C (329˚F)
(50 Hz & 60 Hz Models)
For details of hazardous locations with potential for
explosion, refer to the Canadian Electrical Code, Part 1,
Section 18 or National Electrical Code articles 500-516.
C US
Listed
ISO 9001
