Cf1 technical data – CCI Thermal Technologies CF1 - ProVector Explosion-Proof Convection Heater User Manual
Page 8
All units are single phase
Units can be operated at 50 or 60 Hz
* Or equivalent breaker as per local electrical inspection authority requirements
** Optional thermostats not available as it exceeds current rated capacity.
*** Ensure supply wire size adheres to applicable local and national electrical codes.
NOTES
1. Heater is functioning normally if, at rated voltage, the current draw is within 10% of the value in this table.
2. Operation at lower voltages that rated will result in reduced output and current draw.
Actual Output (kW) = [(Supply Voltage)2 ÷ (Rated Voltage)2] × Rated Unit Wattage (kW)
3. Add suffix "T" for optional built-in thermostat. Thermostat not available on IIB + H2 models.
4. Add suffix "H" for high-temperature ambient storage option. High temperature storage option is not available with thermostat option. Not available on IIB
models.
5. For IIB model with XCT built-in thermostat - Class I, Div. 1 & 2, Groups C & D; Zones 1 & 2, Groups IIA and IIB
6. For IIC model with XTWA built-in thermostat - Class I, Div. 1 & 2, Groups A,B,C & D; Zones 1 & 2, Groups IIA, IIB, IIC
7. IIC Grouping units come with x-Max® housing
8. Remote mounted, Defender, explosion-proof room thermostats are not suitable for Group B & IIC applications
9. Temperature code ratings: T2 - 300°C (572°F), T3 - 200°C (392°F), T4 - 135°C (275°F)
– 8 –
CF1 TECHNICAL DATA
MODEL NUMBER
kW
(BTU/hr)
UNIT
VOLTAGE
(VOLTS)
BASIC
UNIT
GAS GROUP
SUPPLY
WIRE
SIZE
(AWG)***
UNIT
CURRENT
(AMPS)
MAXIMUM
CIRCUIT
FUSE
(AMPS)*
CABINET
LENGTH
mm (in)
TEMP.
CODE
IIB + H2
IIB
IIC
W/O
T'STAT
W/
T'STAT
W/O
T'STAT
W/
T'STAT
CF1-220150-010-T4
1.0 (3412)
220
12
4.6
15
796 (31.3)
T4
CF1-220150-015-T3
1.5 (5118)
220
12
6.9
15
796 (31.3)
T3
CF1-220150-030-T2
3.0 (10236)
220
-
-
12
13.8
15
796 (31.3)
T2
CF1-220150-040-T3
4.0 (13648)
220
-
-
10
18.3
20
1256 (49.4)
T3
CF1-220150-064-T2**
6.4 (21837)
220
-
-
-
8
29.0
30
1511 (59.5)
T2
CF1-230150-011-T4
1.1 (3753)
230
12
4.8
15
796 (31.3)
T4
CF1-230150-017-T3
1.7 (5801)
230
12
7.2
15
796 (31.3)
T3
CF1-230150-030-T3
3.0 (10236)
230
12
13.0
15
1256 (49.4)
T3
CF1-230150-033-T2
3.3 (11260)
230
-
-
10
14.4
15
796 (31.3)
T2
CF1-230150-044-T2
4.4 (15013)
230
-
-
10
19.2
20
1256 (49.4)
T2
CF1-230150-070-T2**
7.0 (23885)
230
-
-
-
8
30.3
35
1511 (59.5)
T2
CF1-240150-012-T4
1.2 (4095)
240
12
5.0
15
796 (31.3)
T4
CF1-240150-018-T3
1.8 (6142)
240
12
7.5
15
796 (31.3)
T3
CF1-240150-030-T3
3.0 (10236)
240
12
12.5
15
1256 (49.4)
T3
CF1-240150-036-T2
3.6 (12284)
240
-
-
10
15.0
20
796 (31.3)
T2
CF1-240150-048-T2
4.8 (16378)
240
-
-
10
20.0
25
1256 (49.4)
T2
CF1-240150-076-T2**
7.6 (25932)
240
-
-
-
8
31.7
35
1511 (59.5)
T2
CF1-254150-030-T3
3.0 (10236)
254
12
11.8
15
1256 (49.4)
T3
CF1-380150-0075-T4
0.75 (2559)
380
12
2.0
15
796 (31.3)
T4
CF1-380150-011-T4
1.1 (3753)
380
12
3.0
15
796 (31.3)
T4
CF1-380150-023-T3
2.3 (7848)
380
-
-
12
5.9
15
796 (31.3)
T3
CF1-380150-030-T3
3.0 (10236)
380
12
7.9
15
1256 (49.4)
T3
CF1-380150-036-T3
3.6 (12284)
380
12
9.4
15
1256 (49.4)
T3
CF1-380150-048-T2
4.8 (16378)
380
-
-
12
12.5
15
1511 (59.5)
T2
CF1-400150-0083-T4
0.83 (2832)
400
12
2.1
15
796 (31.3)
T4
CF1-400150-013-T4
1.3 (4436)
400
12
3.1
15
796 (31.3)
T4
CF1-400150-025-T3
2.5 (8530)
400
-
-
12
6.3
15
796 (31.3)
T3
CF1-400150-033-T3
3.3 (11260)
400
12
8.3
15
1256 (49.4)
T3
CF1-400150-036-T3
3.6 (12284)
400
12
9.0
15
1256 (49.4)
T3
CF1-400150-053-T2
5.3 (18084)
400
-
-
12
13.2
15
1511 (59.5)
T2
CF1-415150-009-T4
0.90 (3071)
415
12
2.2
15
796 (31.3)
T4
CF1-415150-014-T4
1.4 (4777)
415
12
3.2
15
796 (31.3)
T4
CF1-415150-027-T2
2.7 (9213)
415
-
-
12
6.5
15
796 (31.3)
T2
CF1-415150-036-T3
3.6 (12284)
415
12
8.7
15
1256 (49.4)
T3
CF1-415150-057-T2
5.7 (19449)
415
-
-
12
13.7
15
1511 (59.5)
T2
