DRIVESYSTEMS
HELICAL IN-LINE
PARTS LIST DRAWINGS
RETAIN FOR FUTURE USE U15100 - 5 of 12
1 Gear
2 Pinion Shaft
5 Gear
6 Pinion
7 Output Shaft
8 Key
9 Oil Seal
10 Oil Seal
11 Snap Ring
12 Anti-Friction Bearing
13 NILOS ring
14 Gasket
15 Inspection Cover
16 Spacer
17 Vent Plug
18 Seal
19 Bolt
20 Key
21 Spacer
22 Anti-Friction Bearing
23 Thrust Washer
24 Shim
25 Snap Ring
26 Flanged Eye Bolt
27 Bolt
28 Gasket
29 Spacer
30 Input Cover
31 Anti-Friction Bearing
32 Gasket
33 Key
34 Drain Plug 35 Gasket
36 Spacer
37 Anti-Friction Bearing
38 Anti-Friction Bearing
39 Snap Ring
40 Bore Plug
41 Shim
42 Thrust Washer
43 Gearcase
131 NILOS Ring
132 NILOS Ring
918 Key
919 Snap Ring
990 Oil Level Plug
5
16
31
20
8
11
1
23
21
22
25
24
39
41
38
40
2
37
36
29
918
6
919
CUT PINION
SHAFT
10
9
34
35
35
990
33
43
7
26
17
19
15
14
32
30
27
28
12
13
TYPE "AS"
TYPE "A"
PRESS ON
PINION SHAFT
18
42
131
132
SK62 - SK102 Foot Mount
