S E N T I N E L
Document Number: SENT1001 14
Note:
“Wash Output #”refers to the number associated with the arming wires. Refer to the
wash manufacturer documentation for more information.
4. Connect the wash relay arming wires, the wash relay common wire, and any spare option
relay wires to the appropriate pins, as indicated in the following table. Use the screwdriver
to open and/or secure the manufacturer wash wires to each of the Unitec relay locations.
Table 1. Wash Relays
Pin Signal
Pin 1 Wash Output #1
Pin 2 Wash Output #2
Pin 3 Wash Output #3
Pin 4 Wash Output #4
Pins 5-8 Spare Option Relays (Outputs 5-8
respectively)
Pin 9 Wash Relay Common
Pin 10 N/A
5. Plug the Phoenix connector into the Wash I/O board socket J17.
6. Continue to Wash-In-Use wiring procedures.
3.6.3 Wiring the Wash-In-Use Interface
Note: Follow local electrical code when wiring the Sentinel.
Wash equipment requires a reset circuit. This circuit is generally identified as the “Wash-In-Use” (WIU)
signal. It is not uncommon for values of this voltage to be as much as 115-120 VAC, so it is extremely
important to verify that there is no power applied to any of the wash components before proceeding.
3 . 6 . 3 . 1 P r e p a r a t i o n
Note:
Wash equipment wiring may vary, and not all equipment manufacturers use the wash-
fault interface. Refer to the manufacturer’s documentation for additional information.
