S E N T I N E L
Document Number: SENT1001
6
Document Name: Sentinel Installation Manual
Circuit Description
Wire Qty
Wire Requirements
Sentinel Power (115-120 VAC, 8 Amps).
3
16 AWG minimum, black/white/green
Gate Power (115-120 VAC, 5 Amps).
3
16 AWG minimum, black/white/green
Network connection (to router)
1
Cat 5 communications cable, 295 ft max length
Wash Signaling (required if the Sentinel will be
connected to the wash controller)
Varies
Refer to wash equipment manufacturer’s
instructions
Intercom
(Required to interface with site intercom)
4
22 AWG minimum
Camera
(Required for Sentinel camera option)
1
Type RG59/U coaxial cable
Gate Control – from gate controller to Sentinel
(Required if gate controller is used)
4
18 AWG minimum
Gate Control - from gate controller to gate
(Required if gate controller is used)
3
18 AWG minimum
Gate Control – from Sentinel to Gate
(Required if gate is used without gate controller)
4
18 AWG minimum
RFID Option
(from RFID Antenna to Sentinel)
1
Cable is supplied with RFID kit
