CY62138FV30 MoBL

®

Switching Characteristics

(Over the Operating Range)

[11]

Parameter

Description

45 ns

Unit

Min

Max

Read Cycle

t

RC

Read Cycle Time

45

ns

t

AA

Address to Data Valid

45

ns

t

OHA

Data Hold from Address Change

10

ns

t

ACE

CE

1

LOW and CE

2

HIGH to Data Valid

45

ns

t

DOE

OE LOW to Data Valid

22

ns

t

LZOE

OE LOW to Low-Z

[12]

5

ns

t

HZOE

OE HIGH to High-Z

[12,13]

18

ns

t

LZCE

CE

1

LOW and CE

2

HIGH to Low Z

[12]

10

ns

t

HZCE

CE

1

HIGH or CE

2

LOW to High-Z

[12, 13]

18

ns

t

PU

CE

1

LOW and CE

2

HIGH to Power Up

0

ns

t

PD

CE

1

HIGH or CE

2

LOW to Power Down

45

ns

Write Cycle

[14]

t

WC

Write Cycle Time

45

ns

t

SCE

CE

1

LOW and CE

2

HIGH to Write End

35

ns

t

AW

Address Setup to Write End

35

ns

t

HA

Address Hold from Write End

0

ns

t

SA

Address Setup to Write Start

0

ns

t

PWE

WE Pulse Width

35

ns

t

SD

Data Setup to Write End

25

ns

t

HD

Data Hold from Write End

0

ns

t

HZWE

WE LOW to High-Z

[12, 13]

18

ns

t

LZWE

WE HIGH to Low-Z

[12]

10

ns

Notes

11. Test conditions for all parameters other than tri-state parameters assume signal transition time of 3 ns or less (1 V/ns), timing reference levels of V

CC(typ)

/2, input

pulse levels of 0 to V

CC(typ)

, and output loading of the specified I

OL

/I

OH

as shown in the “

“AC Test Loads and Waveforms” on page 4

” .

12. At any given temperature and voltage condition, t

HZCE

is less than t

LZCE

, t

HZOE

is less than t

LZOE

, and t

HZWE

is less than t

LZWE

for any given device.

13. t

HZOE

, t

HZCE

, and t

HZWE

transitions are measured when the output enters a high impedance state.

14. The internal write time of the memory is defined by the overlap of WE, CE

1

= V

IL

, and CE

2

= V

IH

. All signals must be ACTIVE to initiate a write and any of these

signals can terminate a write by going INACTIVE. Reference the data input setup and hold timing to the edge of the signal that terminates the write.
